4Lasers公司的平凸透镜，一面是平面，一面是球面，可用于聚焦准直光束，扩束器以及准直器。该透镜是由优质UV级熔融石英和BK7玻璃制成，标准尺寸为1英寸和半英寸。其用作聚焦镜时，焦距最高可达到10米，最低20mm。这款原装进口透镜价格仅为140元到360元之间。
所属品牌： 立陶宛Optogama
应用类型：
产品型号：Plano-convex spherical lenses
负责人：李工
联系电话：13691926712
电子邮箱：zxli@welloptics.cn
4Lasers平凸透镜，尺寸，焦距20mm~10000mm
平凸球面透镜是最普通的聚焦镜，英文名称为Plano-convex
spherical lenses，其具有一个平面和一个球面凸面，而它们的焦距在凸面的一侧。其可以用于聚焦准直光束，或对点光源发出的光进行准直。平凸球面透镜通常应用于各种工业应用。4Lasers公司提供近100种型号的平凸透镜，标准的透镜直径为12.7mm和25.4mm，边缘厚度2mm，焦距20mm~10000mm，价格140元到300多元不等。
Edmund的对平凸透镜（PCX）分化地更细，例如微型平凸 (PCX) 透镜，超薄平凸 (PCX) 透镜，405nm 镀激光线膜的平凸（PCX)镜片，532nm激光线平凸（PCX)镜片，633nm 激光线平凸（PCX)镜片，785nm 激光线平凸（PCX)镜片，1064nm激光线平凸（PCX)镜片，1550nm 激光线镀膜熔融石英平凸（PCX）透镜，激光级平凸(PCX)透镜，λ/20 平凸透镜，大型PCX聚光镜等。
4Lasers平凸透镜的主要特点：
§材质为UV级熔融石英和BK7玻璃
§标准直径： 12,7mm和25,4mm
§焦距范围：20mm~10000mm
§可根据要求提供抗反射镀膜，定制材料，尺寸和焦距
4Lasers平凸透镜的主要应用：
§聚焦准直光束
§准直来自点光源的光束
§扩束器和准直器
4Lasers平凸透镜的主要参数：
|
平凸透镜 |
|
|
材料 |
BK7，UVFS |
|
波长范围 |
未镀膜BK7镜片：350 nm-2μm，未镀膜UVFS镜片：185 nm-2.1μm
无涂层UVFS镜片：185 nm-2,1μm未涂布的BK7镜片：350 nm-2μm
|
|
通光孔径 |
＞90% |
|
直径公差 |
+0/-0.1mm |
|
厚度公差 |
±0.5mm |
|
中心误差 |
＜3 arcmin
|
|
焦距公差 |
±3%@632.8 nm |
|
倒角 |
<0.35 mm at 45° |
|
表面质量 |
40-20 S-D |
|
面形 |
<λ/8@632.8 nm |
|
镀膜 |
未镀膜，可根据要求提供 |
Optogama平凸透镜的产品订购信息：
以下产品价格对应欧元汇率7.7，价格随汇率浮动。订单金额不满2万需另付800元运保费。
|
SKU型号 |
材料 |
直径 |
边缘厚度 |
焦距 |
价格（RMB） |
|
7014 |
BK7 |
⌀12.7mm |
2mm |
20mm |
141 |
|
7015 |
BK7 |
⌀12.7mm |
2mm |
40mm |
141 |
|
7016 |
BK7 |
⌀12.7mm |
2mm |
50mm |
141 |
|
7017 |
BK7 |
⌀12.7mm |
2mm |
75mm |
141 |
|
7018 |
BK7 |
⌀12.7mm |
2mm |
100mm |
141 |
|
7019 |
BK7 |
⌀12.7mm |
2mm |
150mm |
141 |
|
7020 |
BK7 |
⌀12.7mm |
2mm |
200mm |
141 |
|
7021 |
BK7 |
⌀12.7mm |
2mm |
250mm |
141 |
|
7022 |
BK7 |
⌀12.7mm |
2mm |
300mm |
141 |
|
7023 |
BK7 |
⌀12.7mm |
2mm |
350mm |
141 |
|
7024 |
BK7 |
⌀12.7mm |
2mm |
500mm |
141 |
|
7025 |
BK7 |
⌀12.7mm |
2mm |
1000mm |
141 |
|
7026 |
BK7 |
⌀12.7mm |
2mm |
1500mm |
141 |
|
7118 |
UVFS |
⌀12.7mm |
2mm |
20mm |
300 |
|
7119 |
UVFS |
⌀12.7mm |
2mm |
40mm |
300 |
|
7120 |
UVFS |
⌀12.7mm |
2mm |
50mm |
300 |
|
7121 |
UVFS |
⌀12.7mm |
2mm |
75mm |
300 |
|
7122 |
UVFS |
⌀12.7mm |
2mm |
100mm |
300 |
|
7123 |
UVFS |
⌀12.7mm |
2mm |
150mm |
300 |
|
7124 |
UVFS |
⌀12.7mm |
2mm |
200mm |
300 |
|
7125 |
UVFS |
⌀12.7mm |
2mm |
300mm |
300 |
|
7126 |
UVFS |
⌀12.7mm |
2mm |
400mm |
300 |
|
7127 |
UVFS |
⌀12.7mm |
2mm |
500mm |
300 |
|
7128 |
UVFS |
⌀12.7mm |
2mm |
700mm |
300 |
|
7129 |
UVFS |
⌀12.7mm |
2mm |
1000mm |
300 |
|
7130 |
UVFS |
⌀12.7mm |
2mm |
1500mm |
300 |
|
7134 |
BK7 |
⌀25.4mm |
2mm |
30mm |
224 |
|
7135 |
BK7 |
⌀25.4mm |
2mm |
40mm |
179 |
|
7136 |
BK7 |
⌀25.4mm |
2mm |
50mm |
179 |
|
7137 |
BK7 |
⌀25.4mm |
2mm |
60mm |
179 |
|
7138 |
BK7 |
⌀25.4mm |
2mm |
75mm |
179 |
|
7141 |
BK7 |
⌀25.4mm |
2mm |
100mm |
179 |
|
7142 |
BK7 |
⌀25.4mm |
2mm |
125mm |
179 |
|
7143 |
BK7 |
⌀25.4mm |
2mm |
150mm |
179 |
|
7144 |
BK7 |
⌀25.4mm |
2mm |
175mm |
179 |
|
7145 |
BK7 |
⌀25.4mm |
2mm |
200mm |
179 |
|
7146 |
BK7 |
⌀25.4mm |
2mm |
250mm |
179 |
|
7147 |
BK7 |
⌀25.4mm |
2mm |
300mm |
179 |
|
7148 |
BK7 |
⌀25.4mm |
2mm |
400mm |
179 |
|
7149 |
BK7 |
⌀25.4mm |
2mm |
500mm |
179 |
|
7150 |
BK7 |
⌀25.4mm |
2mm |
700mm |
179 |
|
7151 |
BK7 |
⌀25.4mm |
2mm |
1000mm |
179 |
|
7152 |
BK7 |
⌀25.4mm |
2mm |
1500mm |
179 |
|
7153 |
BK7 |
⌀25.4mm |
2mm |
2000mm |
179 |
|
7154 |
BK7 |
⌀25.4mm |
2mm |
3000mm |
179 |
|
7155 |
BK7 |
⌀25.4mm |
2mm |
4000mm |
179 |
|
7156 |
BK7 |
⌀25.4mm |
2mm |
5000mm |
179 |
|
7157 |
BK7 |
⌀25.4mm |
2mm |
2500mm |
179 |
|
7158 |
BK7 |
⌀25.4mm |
2mm |
10000mm |
179 |
|
7159 |
UVFS |
⌀25.4mm |
2mm |
30mm |
357 |
|
7160 |
UVFS |
⌀25.4mm |
2mm |
40mm |
357 |
|
7161 |
UVFS |
⌀25.4mm |
2mm |
50mm |
357 |
|
7162 |
UVFS |
⌀25.4mm |
2mm |
60mm |
357 |
|
7163 |
UVFS |
⌀25.4mm |
2mm |
75mm |
357 |
|
7166 |
UVFS |
⌀25.4mm |
2mm |
100,mm |
357 |
|
7167 |
UVFS |
⌀25.4mm |
2mm |
125mm |
357 |
|
7168 |
UVFS |
⌀25.4mm |
2mm |
150mm |
357 |
|
7169 |
UVFS |
⌀25.4mm |
2mm |
175mm |
357 |
|
7170 |
UVFS |
⌀25.4mm |
2mm |
200mm |
357 |
|
7171 |
UVFS |
⌀25.4mm |
2mm |
250mm |
357 |
|
7172 |
UVFS |
⌀25.4mm |
2mm |
300mm |
357 |
|
7173 |
UVFS |
⌀25.4mm |
2mm |
400mm |
357 |
|
7174 |
UVFS |
⌀25.4mm |
2mm |
500mm |
357 |
|
7175 |
UVFS |
⌀25.4mm |
2mm |
750mm |
357 |
|
7176 |
UVFS |
⌀25.4mm |
2mm |
1000mm |
357 |
|
7177 |
UVFS |
⌀25.4mm |
2mm |
1500mm |
357 |
|
7178 |
UVFS |
⌀25.4mm |
2mm |
2000mm |
357 |
|
7179 |
UVFS |
⌀25.4mm |
2mm |
3000mm |
357 |
|
7180 |
UVFS |
⌀25.4mm |
2mm |
4000mm |
357 |
|
7181 |
UVFS |
⌀25.4mm |
2mm |
5000mm |
357 |
|
7182 |
UVFS |
⌀25.4mm |
2mm |
7000mm |
357 |
|
7183 |
UVFS |
⌀25.4mm |
2mm |
10000mm |
357 |
